Up to 940 sqm/h

A Special Printer Tailored to Special Home Textiles

      Featuring a width of 340mm, aleph’s LAFORTE 340 has been designed to address the specific needs of home textiles market segment. Streamlining the production of wallpapers, curtains, drapery and upholstery, this direct-to-textile inkjet printing solution enables to achieve superior print quality, high speed (up to 570 sqm/h) with high fastness and at a competitive cost.

      Speed

      Up to 570 sqm/h – 8 Print Head

      Up to 380 sqm/h – 8 Print Head

      Up to 940 sqm/h – 16 Print Head

      Up to 630 sqm/h – 16 Print Head

      *All the printing speeds have been calculated based on 3000mm-width printer and may vary depending on the substrates, the level of the quality and the selected print width.

      Key features



      Anti mist System


      Printing technology
      Variable drop inkjet from 4pl to 72pl
      (2.656 nozzles - 2 colors)


      Printing resolution
      300 / 600 / 900 / 1200


      Ink tank capacity
      5/10/20 kg/lt


      Media feeding system
      Rotary sticky belt system
      Advancement accuracy 40 microns


      Water consumption
      25-50 L/h


      Interface
      Ethernet 10 GB


      DST - aleph® HQ multi-pass printing
      Dynamic stitching technology

      Printer models and specs

      POWER SETTING
      19 kW / 3 phases+neutral /
      380–420V ±10% / 16A

      COMPRESSED AIR CONSUMPTION
      6-8 bar – 250 L/min

      WATERCONSUMPTION
      w20-50 L/h

      DIMENSIONS
      6180×2100×h 2400 mm

      WEIGHT
      4.400 kg
