Dryer LAFORTE Fabric
Advanced high-speed fabric drying technology featuring infrared plasma lamps
aleph's LAFORTE Fabric dryer series features advanced proprietary rapid drying systems engineered to enable efficient drying of digitally printed fabrics with water-based inks.
The drying systems of the series are equipped with an infrared plasma lamp unit, available in different print sizes (1800mm, 2200mm, 3400mm) and can achieve a production speed of up to 600sqm/h. Featuring internal temperature sensors and an innovative control software, the drying systems allow to keep the drying temperature monitored and under control. The use of ultrasonic sensors enables continuous fabric recovery.
Designed with flexibility and ease of use in mind, LAFORTE Fabric dryers can connect and interface with any industrial inkjet textile plotter available on the market.
Speed
Up to 600 sqm/h
Key features
aleph intelly oven
Printer models and specs
Dryer LAFORTE 100 Fabric (190 Model)
UNIT DIMENSIONS: 3100x1700x1200mm
WEIGHT: 650 kg
INFRARED LAMPS: 15
POWER SETTING: 19 kW / 3 phases+neutral / 380–420V ±10% / 16A
Dryer LAFORTE 200 Fabric (190 Model)
UNIT DIMENSIONS: 2760x930x1200mm
WEIGHT: 550 kg
INFRARED LAMPS: 10
POWER SETTING: 14 kW / 3 phases+neutral / 380–420V ±10% / 16A
Dryer LAFORTE 400 Fabric (190 Model)
UNIT DIMENSIONS: 3100x2300x1200mm
WEIGHT: 700 kg
INFRARED LAMPS: 15
POWER SETTING: 19 kW / 3 phases+neutral / 380–420V ±10% / 16A
Dryer LAFORTE 400 Fabric (220 Model)
UNIT DIMENSIONS: 3400x2300x1200mm
WEIGHT: 700 kg
INFRARED LAMPS: 18
POWER SETTING: 22 kW / 3 phases+neutral / 380–420V ±10% / 16A
