Up to 200 sqm/h

Cost-effective Sublimation Digital Printer

      LAFORTE 100 Paper is a versatile and cost-effective inkjet printing system. A water-based dye-sublimation entry-level solution with production speed up to 200 sqm/h, LAFORTE 100 Paper has been designed to address low to mid print volume production in the out of home space at large and is ideal for exploring new market segments and diversify the product portfolio.

      Speed

      Up to 200 sqm/h

      Up to 100 sqm/h

      *All the printing speeds have been calculated based on 1600mm-width printer and may vary depending on the substrates, the level of the quality and the selected print width.

      Key features



      Anti mist System


      Printing technology
      Variable drop inkjet from 4pl to 72pl
      (2.656 nozzles - 2 colors)


      Printing resolution
      300 / 600 / 900 / 1200


      Ink tank capacity
      5/10/20 kg/lt


      Media feeding system
      Rotary sticky belt system
      Advancement accuracy 40 microns


      Interface
      Ethernet 10 GB


      DST - aleph® HQ multi-pass printing
      Dynamic stitching technology

      Printer models and specs

      POWER SETTINGS
      16 kW / 3 phases+neutral / 380–420V ±10% / 16A

      COMPRESSED AIR CONSUMPTION
      6-8 bar – 250 L/min



      DIMENSIONS
      4700×2590×h 2250 mm

      WEIGHT
      2.700 kg

      Areas of Applications
