Up to 680 sqm/h

Taking Soft Signage to the Next Level

      Featuring 8 printheads and a width of 320mm, LAFORTE 320 has been designed to address the soft signage market segment. Streamlining the production of indoor and outdoor textile-based communications in all sizes, aleph’s LAFORTE 320 WIDE PAPER enables to achieve high-speed (up to 680 sqm/h), superior print quality with high-level fastness, at a competitive cost and through an environmentally friendly process.

      Speed

      Up to 680 sqm/h – 8 Print Head

      Up to 380 sqm/h – 8 Print Head

      Up to 1000 sqm/h – 16 Print Head

      Up to 760 sqm/h – 16 Print Head

      *All the printing speeds have been calculated based on 3000mm-width printer and may vary depending on the substrates, the level of the quality and the selected print width.

      Key features



      Anti mist System


      Printing technology
      Variable drop inkjet from 4pl to 72pl
      (2.656 nozzles - 2 colors)


      Printing resolution
      300 / 600 / 900 / 1200


      Ink tank capacity
      5/10/20 kg/lt


      Media feeding system
      Rotary sticky belt system
      Advancement accuracy 40 microns


      Interface
      Ethernet 10 GB


      DST - aleph® HQ multi-pass printing
      Dynamic stitching technology

      Printer models and specs

      POWER SETTINGS
      19 kW / 3 phases+neutral /
      380–420V ±10% / 16A

      COMPRESSED AIR CONSUMPTION
      6-8 bar – 250 L/min

      DIMENSIONS
      6180 L x 2100 P x 2400 H mm

      WEIGHT
      4.400 Kg

      Areas of Applications
