Up to 380 sqm/h

A Must-have Solution for Mid to High Print Volumes

      LAFORTE 200 Paper is an industrial dye-sublimation inkjet printer, featuring a compact design and a patented rotary belt. Designed to address mid to high print volume production (up to 380 sqm/h), the printer enables high-quality images and extreme application flexibility.

      Speed

      Up to 380 sqm/h

      Up to 250 sqm/h

      *All the printing speeds have been calculated based on 1600mm-width printer and may vary depending on the substrates, the level of the quality and the selected print width.

      Key features



      Anti mist System


      Printing technology
      Variable drop inkjet from 4pl to 72pl
      (2.656 nozzles - 2 colors)


      Printing resolution
      300 / 600 / 900 / 1200


      Ink tank capacity
      5/10/20 kg/lt


      Media feeding system
      Rotary sticky belt system
      Advancement accuracy 40 microns


      Interface
      Ethernet 10 GB


      DST - aleph® HQ multi-pass printing
      Dynamic stitching technology

      Printer models and specs

      POWER SETTINGS
      16 kW / 3 phases+neutral /
      380–420V ±10% / 16A

      COMPRESSED AIR CONSUMPTION
      6-8 bar – 250 L/min

      DIMENSIONS
      4680 L x 2100 P x 2400 H mm

      WEIGHT
      2.700 Kg

      Areas of Applications

      Request
      information
